ASME B16.5 Slip On Flanges Dimensions
ANSI/ASME/ASA B16.5 150lb/sq.in. Flange SO-RF |
||||||||||
ø |
D |
b |
g |
m |
J |
h |
k |
Holes |
l |
Kg. |
1/2" |
88,9 |
11,1 |
34,9 |
30,2 |
22,3 |
15,9 |
60,3 |
4 |
15,9 |
0,400 |
3/4" |
98,4 |
12,7 |
42,9 |
38,1 |
27,7 |
15,9 |
69,8 |
4 |
15,9 |
0,700 |
1" |
107,9 |
14,3 |
50,8 |
49,2 |
34,5 |
17,5 |
79,4 |
4 |
15,9 |
0,800 |
1 1/4" |
117,5 |
15,9 |
63,5 |
58,8 |
43,2 |
20,6 |
88,9 |
4 |
15,9 |
1,100 |
1 1/2" |
127,0 |
17,5 |
73,0 |
65,1 |
49,5 |
22,2 |
98,4 |
4 |
15,9 |
1,400 |
2" |
152,4 |
19,0 |
92,1 |
77,8 |
62,0 |
25,4 |
120,6 |
4 |
19,0 |
2,200 |
2 1/2" |
177,8 |
22,2 |
104,8 |
90,5 |
74,7 |
28,6 |
139,7 |
4 |
19,0 |
3,600 |
3" |
190,5 |
23,8 |
127,0 |
107,9 |
90,7 |
30,2 |
152,4 |
4 |
19,0 |
4,100 |
3 1/2" |
215,9 |
23,8 |
139,7 |
122,2 |
103,4 |
31,7 |
177,8 |
8 |
19,0 |
5,200 |
4" |
228,6 |
23,8 |
157,2 |
134,9 |
116,1 |
33,3 |
190,5 |
8 |
19,0 |
5,600 |
5" |
254,0 |
23,8 |
185,7 |
163,6 |
143,8 |
36,5 |
215,9 |
8 |
22,2 |
6,300 |
6" |
279,4 |
25,4 |
215,9 |
192,1 |
170,7 |
39,7 |
241,3 |
8 |
22,2 |
7,500 |
8" |
342,9 |
28,6 |
269,9 |
246,1 |
221,5 |
44,4 |
298,4 |
8 |
22,2 |
12,600 |
10" |
406,4 |
30,2 |
323,8 |
304,8 |
276,3 |
49,2 |
361,9 |
12 |
25,4 |
18,500 |
12" |
482,6 |
31,7 |
381,0 |
365,1 |
327,1 |
55,6 |
431,8 |
12 |
25,5 |
28,000 |
14" |
533,4 |
34,9 |
412,7 |
400,0 |
359,1 |
57,1 |
476,2 |
12 |
28,6 |
36,000 |
16" |
596,9 |
36,5 |
469,9 |
457,2 |
410,5 |
63,5 |
539,7 |
16 |
28,6 |
46,000 |
18" |
635,0 |
39,7 |
533,4 |
504,8 |
461,8 |
68,3 |
577,8 |
16 |
31,7 |
50,000 |
20" |
698,5 |
42,9 |
584,2 |
558,8 |
513,1 |
73,0 |
635,0 |
20 |
31,7 |
64,000 |
22" |
749,3 |
46,0 |
641,2 |
609,6 |
564,4 |
79,4 |
692,1 |
20 |
34,9 |
72,000 |
24" |
812,8 |
47,6 |
692,1 |
663,6 |
615,9 |
82,5 |
749,3 |
20 |
34,9 |
89,000 |
ANSI/ASME/ASA B16.5 600lb/sq.in. Flange WN-RF |
||||||||||
ø |
D |
b |
g |
m |
J |
h |
k |
Holes |
l |
Kg. |
1/2" |
95,2 |
14,3 |
34,9 |
38,1 |
22,3 |
22,2 |
66,7 |
4 |
15,9 |
0,800 |
3/4" |
117,5 |
15,9 |
42,9 |
47,6 |
27,7 |
25,4 |
82,5 |
4 |
19,0 |
1,400 |
1" |
123,8 |
17,5 |
50,8 |
54,0 |
34,5 |
27,0 |
88,9 |
4 |
19,0 |
1,600 |
1 1/4" |
133,3 |
20,6 |
63,5 |
63,5 |
43,2 |
28,6 |
98,4 |
4 |
19,0 |
2,100 |
1 1/2" |
155,6 |
22,2 |
73,0 |
69,8 |
49,5 |
31,7 |
114,3 |
4 |
22,2 |
3,100 |
2" |
165,1 |
25,4 |
92,1 |
84,1 |
62,0 |
36,5 |
127,0 |
8 |
19,0 |
3,700 |
2 1/2" |
190,5 |
28,6 |
104,8 |
100,0 |
74,7 |
41,3 |
149,2 |
8 |
22,2 |
5,400 |
3" |
209,5 |
31,7 |
127,0 |
117,5 |
90,7 |
46,0 |
168,3 |
8 |
22,2 |
7,300 |
3 1/2" |
228,6 |
34,9 |
139,7 |
133,3 |
103,4 |
49,2 |
184,1 |
8 |
25,4 |
8,900 |
4" |
273,0 |
38,1 |
157,2 |
152,4 |
116,1 |
54,0 |
215,9 |
8 |
25,4 |
11,800 |
5" |
330,2 |
44,4 |
185,7 |
188,9 |
143,8 |
60,3 |
266,7 |
8 |
28,6 |
24,500 |
6" |
355,6 |
47,6 |
215,9 |
222,2 |
170,7 |
66,7 |
292,1 |
12 |
28,6 |
29,500 |
8" |
419,1 |
55,6 |
269,9 |
273,0 |
221,5 |
76,2 |
349,2 |
12 |
31,7 |
43,000 |
10" |
508,0 |
63,5 |
323,8 |
342,8 |
276,3 |
85,7 |
431,8 |
16 |
34,9 |
70,000 |
12" |
558,8 |
66,7 |
381,0 |
400,0 |
327,1 |
92,1 |
488,9 |
20 |
34,9 |
86,000 |
14" |
603,2 |
69,8 |
412,7 |
431,8 |
359,1 |
93,7 |
527,0 |
20 |
38,1 |
100,000 |
16" |
685,8 |
76,2 |
469,9 |
495,3 |
410,5 |
106,4 |
603,2 |
20 |
41,3 |
142,000 |
18" |
742,9 |
82,5 |
533,4 |
546,1 |
461,8 |
117,5 |
654,0 |
20 |
44,4 |
175,000 |
20" |
812,8 |
88,9 |
584,2 |
609,6 |
513,1 |
127,0 |
723,9 |
24 |
44,4 |
232,000 |
22" |
869,9 |
95,2 |
641,2 |
666,7 |
564,4 |
133,3 |
777,9 |
24 |
47,6 |
292,000 |
24" |
939,8 |
101,6 |
692,1 |
717,5 |
615,9 |
139,7 |
838,2 |
24 |
50,8 |
330,000 |
DIN86029 PN10 Hubbed Slip-on Flange For Welding
DIN86029 PN10 Hubbed Slip-on Flange For Welding in forged steel, Stainless Steel, Carbon steel: C22.8, RST37.2, S235JR, P235GH, P245GH, P250GH, ASTM A105, ASTM A182 F304 (1.4306), F304L(1.4307), F316(1.4404), F316L(1.4404), F321(1.4541) etc.
Rated Diameter |
O.D. of Pipe |
Flange Parameter |
Neck Size |
Size of R.F. |
Bolts |
Approx. Weight |
|||||||
| DN | d1 | D | d5 | b | k | h | d3 | r | d4 | f | No. of holes |
d2 | KG |
10 |
17.2 |
90 |
17.7 |
14 |
60 |
20 |
30 |
4 |
40 |
2 |
4 |
14 |
0.56 |
15 |
21.3 |
95 |
22 |
14 |
65 |
20 |
35 |
4 |
45 |
2 |
4 |
14 |
0.62 |
20 |
26.9 |
105 |
27.6 |
16 |
75 |
24 |
45 |
4 |
58 |
2 |
4 |
14 |
0.91 |
25 |
33.7 |
115 |
34.4 |
16 |
85 |
24 |
52 |
5 |
68 |
2 |
4 |
14 |
1.09 |
32 |
42.4 |
140 |
43.1 |
16 |
100 |
26 |
60 |
5 |
78 |
2 |
4 |
18 |
1.58 |
40 |
48.3 |
150 |
49 |
16 |
110 |
26 |
70 |
5 |
88 |
3 |
4 |
18 |
1.76 |
50 |
60.3 |
165 |
61.1 |
18 |
125 |
28 |
85 |
5 |
102 |
3 |
4 |
18 |
2.39 |
65 |
76.1 |
185 |
77.1 |
18 |
145 |
32 |
105 |
5 |
122 |
3 |
4 |
18 |
3.1 |
80 |
88.9 |
200 |
90.3 |
20 |
160 |
34 |
118 |
5 |
138 |
3 |
8 |
18 |
3.77 |
100 |
114.3 |
220 |
115.9 |
20 |
180 |
38 |
140 |
5 |
158 |
3 |
8 |
18 |
4.29 |
125 |
139.7 |
250 |
141.6 |
22 |
210 |
40 |
168 |
5 |
188 |
3 |
8 |
18 |
5.86 |
150 |
168.3 |
285 |
170.5 |
22 |
240 |
44 |
196 |
5 |
212 |
3 |
8 |
22 |
7.22 |
175 |
193.7 |
315 |
196.1 |
24 |
270 |
44 |
224 |
6 |
242 |
3 |
8 |
22 |
9.18 |
200 |
219.4 |
340 |
222 |
24 |
295 |
44 |
247 |
6 |
268 |
3 |
8 |
22 |
9.95 |
250 |
273 |
395 |
276 |
26 |
350 |
46 |
300 |
6 |
320 |
3 |
12 |
22 |
12.69 |
300 |
323.9 |
445 |
327 |
26 |
400 |
46 |
352 |
6 |
370 |
4 |
12 |
22 |
14.4 |
350 |
355.6 |
505 |
359 |
26 |
460 |
53 |
398 |
10 |
430 |
4 |
16 |
22 |
22.36 |
400 |
406.4 |
565 |
410 |
26 |
515 |
57 |
448 |
10 |
482 |
4 |
16 |
26 |
26.85 |
450 |
457 |
615 |
461 |
28 |
565 |
62 |
502 |
10 |
532 |
4 |
20 |
26 |
32.53 |
500 |
508 |
670 |
512 |
28 |
620 |
67 |
552 |
10 |
585 |
4 |
20 |
26 |
37.84 |
600 |
610 |
780 |
614 |
28 |
725 |
75 |
658 |
10 |
685 |
5 |
20 |
30 |
49.32 |
700 |
711 |
895 |
716 |
30 |
840 |
77 |
760 |
10 |
800 |
5 |
24 |
30 |
63.86 |
800 |
813 |
1015 |
818 |
32 |
950 |
84 |
864 |
10 |
905 |
5 |
24 |
33 |
85.19 |
900 |
914 |
1115 |
920 |
34 |
1050 |
88 |
969 |
10 |
1005 |
5 |
28 |
33 |
101.4 |
1000 |
1016 |
1230 |
1022 |
34 |
1160 |
92 |
1071 |
10 |
1110 |
5 |
28 |
36 |
119.7 |
Standard Specification For Slip On Flanges
Size : 1/2" (15 NB) to 48" (1200NB)
Dimensions : ANSI B16.5, ANSI B16.47 Series A & B, MSS SP44, ASA, API-605, AWWA, Custom Drawings
DIN : DIN2527, DIN2566, DIN2573, DIN2576, DIN2641, DIN2642, DIN2655, DIN2656, DIN2627, DIN2628, DIN2629, DIN 2631, DIN2632, DIN2633, DIN2634, DIN2635, DIN2636,DIN2637, DIN2638, DIN2673
Class : 150 LBS, 300 LBS, 600 LBS, 900 LBS, 1500 LBS, 2500 LBS, DIN Standard ND-6,10, 16, 25, 40 Etc.
Flange Face Type : Flate Face (FF), Raised Face (RF), Ring Type Joint (RTJ)
BS : BS4504 , BS4504, BS1560, BS10
Material & Grades of Slip On Flanges (SORF) :
Duplex & Super Duplex Steel Slip On Flanges :
ASTM / ASME A/SA 182 F 44, F 45, F51, F 53, F 55, F 60, F 61.
Stainless Steel Slip On Flanges :
ASTM A 182, A 240 F 304, 304L, 304H, 316, 316L, 316Ti, 310, 310S, 321, 321H, 317, 347, 347H, 904L.
Low Temperature Carbon Steel Slip on Flanges : ASTM A350, LF2, LF3
Carbon Steel Slip On Flanges :
ASTM / ASME A/SA 105 ASTM / ASME A 350 , ASTM A 181 LF 2 / A516 Gr.70 A36, A694 F42, F46, F52, F60, F65, F706
Copper Alloy Steel Slip On Flanges : ASTM SB 61 , SB62 , SB151 , SB152 UNS No. C 70600 (Cu-Ni 90/10), C 71500 (Cu-Ni 70/30), UNS No. C 10100, 10200, 10300, 10800, 12000, 12200
Alloy Steel Slip On Flanges :
ASTM / ASME A/SA 182 & A 387 F1, F5, F9, F11, F12, F22, F91
Nickel Alloy Slip On Flanges :
ASTM SB564, SB160, SB472, SB162 Nickel 200 (UNS No. N02200), Nickel 201 (UNS No. N02201), Monel 400 (UNS No. N04400), Monel 500 (UNS No. N05500), Inconel 800 (UNS No. N08800), Inconel 825 (UNS No. N08825), Inconel 600 (UNS No. N06600), Inconel 625 (UNS No. N06625), Inconel 601 (UNS No. N06601), Hastelloy C 276 (UNS No. N10276), Alloy 20 (UNS No. N08020)
ASME B16.5 Raised Faced Slip-On Flanges Available Types
| ANSI B16.5 Slip On Flanges | Slip on Flange Dimensions |
| Slip on Raised Face Flange | Raised Faced Slip-On Flanges |
| Stainless Steel Slip on Flanges Suppliers | SS Slip on Flange |
| ASME B16.5 SORF Flanges | ANSI B16.5 Class 150 Slip-On Flanges |
| Slip on Plate Flanges Dealer | ASME B16.47 Series A and B SORF Flanges Exporter |
| ANSI B16.5 class 150 SORF Flange Stockholder | ANSI 150 Slip on Flange Distributors |
| Carbon Steel Slip on Flange | High Quality SORF Flanges Manufacturer |
| ASTM A182 Stainless Steel SORF Flange | Duplex Steel Slip on Flange |
| Super Duplex Steel Slip on Forged Flange | Copper Nickel Slip on Pipe Flanges |
| High Nickel Alloy SORF Flanges | Hastelloy Flat Faced Slip-On Flanges Stockist |
| Titanium ASME B16.47 Series A and B SORF Flanges | Inconel Slip on Flanges |
ANSI B16.5 Slip On Flange Application
- Power Plants
- Industrial Boilers
- Oil & Gas Industry
- Nuclear Plants
- Ship Building
- Refineries
- Condensers
- Heat Exchangers
- Marine Applications
- Paper & Pulp
- Fossil Fuel Power Plants
- Nuclear Power
