Incoloy Alloy 800 N08800|Incoloy Alloy 800H N08810|Incoloy Alloy 800HT N08811|Incoloy Alloy 800/800H/800HT Hot rolled plate Coils & Strips|Incoloy Alloy 800/800H/800HT Cold rolled sheet Coils & Strips Stockist|Incoloy Alloy 800/800H/800HT Coils & Strips Supplier In Mumbai.
ASTM A 168 Incoloy Alloy 800/800H/800HT Coils & Strips|ASME SB 168 Incoloy Alloy 800/800H/800HT Coils & Strips Exporter| Incoloy Alloy 800/800H/800HT Coils & Strips|Incoloy Alloy 800/800H/800HT Strips Exporter In India|Incoloy Alloy 800H Coils & Strips|Incoloy Alloy 800HT Coils & Strips|Incoloy Alloy 800 Coils & Strips.
Labh Steel Labh Steel is one of the fundamental Supplier,Stockist and Exporter of Inconel 800, 800H, 800HT coils-strips Incoloy 800 is a nickel-chromium alloy with high strength and superb resistance & Incoloy 800H and 800 HT are nickel-iron-chromium alloys. We are a leading supplier and exporter of Incoloy 800/800H/800HT Strips& Coils. We provide Incoloy Alloy 800/800H/800HT Strips & Coils globally as per made to order requirements given by our highly valued clients, to meet the quality demands of our customers..
Incoloy alloy 800/H/HT is broadly utilized for development of gear requiring erosion resistance, heat resistance, quality, and dependability for administration up to 1500°F (816°C). Alloy 800/H/HT offers general erosion imperviousness to numerous fluid media and opposes stress consumption breaking. Incoloy 800H has lower carbon content and higher crawl and break resistance. Incoloy 800/800H/HT has further changes to the consolidated titanium and aluminum levels (0.85-1.20%) to guarantee ideal high temperature properties.
SPECIFICATIONS OF INCOLOY ALLOY 800/800H/800 HT COILS & STRIPS :
Standard : |
AISI, ASTM, DIN, JIS, GB, BS |
Thickness : |
0.3mm~15mm |
Specifications : |
ASTM / ASME SB 168, ASTM / ASME SB 424 , ASTM / ASME SB 443 |
Width : |
3.5mm~2000mm |
Grade : |
Incoloy Alloy 800/800H/800HT Coils & Strips |
Range: |
0.3mm to 150mm |
Form: |
Coils, Foils, Rolls, Plain Sheet, Shim Sheets, Perforated Sheets, Chequered Plates, Strips, Flats, Blank (Circle), Ring (Flange) etc. |
Hardness: |
Soft, Hard, Half Hard, Spring Hard, etc. |
Finish: |
Hot rolled plates (HR), Cold rolled sheets (CR), 2B, 2D, 2BB, BA, NO8, SATIN (MET with Plastic coated). |
Other services: |
Heat treatment, Annealing, Pickling, Polish, Electroplating, Anodizing, Rolling, Cutting, Forging, etc. |
GRADE SPECIFICATIONS OF INCOLOY ALLOY 800/800H/800HT COILS & STRIPS :
| Inconel Alloy | Tradename | UNS no. | Werkstoff No. |
| 800 | Incoloy Alloy 800 | N08800 | 1.4876 |
| 800H | Incoloy Alloy 800H | N08810 | 1.4876 |
| 800HT | Incoloy Alloy 800HT | N08811 | 1.4876 |
CHEMICAL COMPOSITION OF INCOLOY ALLOY 800/800H/800HT COILS & STRIPS :
|
Alloy |
Ni |
Fe |
Cr |
Cu |
Ti |
Al |
C |
Mn |
S |
Si |
|
30.0-35.0 |
39.5 min |
19.0-23.0 |
.75 max |
.15-.60 |
.15-.60 |
.1 max |
1.5 max |
.015 max |
1.0 max |
|
|
Alloy 800H |
Ni |
Fe |
Cr |
Cu |
Ti |
Al |
C |
Mn |
S |
Si |
|
30.0-35.0 |
39.5 min |
19.0-23.0 |
.75 max |
.15-.60 |
.15-.60 |
.05-.10 max |
1.5 max |
.015 max |
1.0 max |
|
|
Alloy 800HT |
Ni |
Fe |
Cr |
Cu |
Ti |
Al |
C |
Mn |
S |
Si |
|
30.0-35.0 |
39.5 min |
19.0-23.0 |
.75 max |
.25-.60 |
.85-1.20 |
.06-.10 max |
1.5 max |
.015 max |
1.0 max |
MECHANICAL PROPERTIES OF INCOLOY ALLOY 800/800H/800HT COILS & STRIPS :
|
|
INCOLOY 800 |
INCOLOY 800H |
INCOLOY 800HT |
|
Density |
7.94 g/cm3 |
7.94 g/cm3 |
7.94 g/cm3 |
|
Melting Range,℃ |
1350-1400 ℃ |
1350-1400 ℃ |
1350-1400 ℃ |
|
Elongation % |
30-35 |
30-35 |
30-35 |
|
Tensile strength – Mpa |
500 |
500 |
500 |
|
Yield strength – Mpa |
205 |
200 |
200 |
