Monel Alloy K-500 Plain End Sheets & Plates|Monel Alloy K-500 Bevelled End Sheets & Plates|Monel Alloy K-500 Threaded Sheets & Plates|2.4375 Monel Alloy K-500 Sheets & Plates Exporter|Monel Alloy K-500 Sheets & Plates Supplier In Mumbai.
Monel Alloy K-500 N05 500 Stockist| Monel Alloy K-500 Sheets & Plates|Monel Alloy K-500 Sheets & Plates Exporter In India|ASTM B 127 Monel Alloy K-500 Sheets & Plates|ASME SB 127 Monel Alloy K-500 Sheets & Plates.
Labh Steelwe are Supplier and Exporter of Monel Alloy K-500 Sheets & Plates In India, Mumbai. we produce our materials using high quality raw materials for high resistance of our product. we also provide various grades ASTM B 127 / ASME SB 127. we also take on clients requests as per their specifications.we offer various types of Monel Alloy K-500 Sheets & Plates such as Plain End, Bevelled End, Threaded.
Monel depends on copper (20-29%) and nickels (65-70%) and too contains manganese and iron (5%) along woth different mixes. They are broadly utilized as a part of various application commercial ventures like Chemicals, Fats and Fertilizers, Ship Builders, Sugar Mills and Distilleries, Paper Industries, Cement Industries, thus on.
Monel K500 Sheets and Plates can likewise be supplied in made to request length sizes and too machined or created to meet clients necessities in Pipeing framework.
SPECIFICATIONS OF MONEL ALLOY K-500 SHEETS PLATES :
| Standards : | ASTM B 127 / ASME SB 127 |
| Type : | Sheet, Plates, Plain Sheets |
| Grades : | Monel Alloy K-500 - UNS N05500 |
| Length : | Single Random, Double Random & Cut Length |
| End : | Plain End, Bevelled End, Threaded |
| Range : | 0.3mm to 150mm |
| Hardness : | Hardness: Soft, Hard, Half Hard, Spring Hard, etc. |
| Finish : | Hot rolled plates (HR), Cold rolled sheets (CR), 2B, 2D, 2BB, BA, NO8, SATIN (MET with Plastic coated). |
| Form: | Coils, Foils, Rolls, Plain Sheet, Shim Sheets, Perforated Sheets, Chequered Plates, Strips, Flats, Blank (Circle), Ring (Flange) etc. |
| Other services : | Heat treatment, Annealing, Pickling, Polish, Electroplating, Anodizing, Rolling, Cutting, Forging, etc. |
GRADE SPECIFICATIONS OF MONEL ALLOY K-500 SHEETS PLATES :
| Monel Alloy | Tradename | UNS no. | Werkstoff No. |
| K-500 | Monel Alloy K-500 | N05500 | 2.4375 |
CHEMICAL COMPOSITION OF MONEL ALLOY K-500 SHEETS PLATES :
Monel K-500 |
Ni |
Mn |
Si |
Fe |
Al |
S |
C |
Max |
- |
1.50 |
0.50 |
2.00 |
3.15 |
0.010 |
0.18 |
Min- |
63.00 |
- |
- |
- |
2.30 |
- |
- |
MECHANICAL PROPERTIES OF MONEL ALLOY K-500 SHEETS PLATES :
Condition |
Tensile (ksi) |
.2% Yield (ksi) |
Elongation % |
Hardness |
|---|---|---|---|---|
Hot-Finished/Aged |
140-190 |
100-150 |
30-20 |
27-38 HRC |
Hot Finished/Annealed |
90-110 |
40-60 |
45-25 |
75-90 HRB |
Hot Finished/Annealed/Aged |
130-165 |
85-120 |
35-20 |
24-35 HRC |
Cold-Drawn/Aged |
135-185 |
95-160 |
30-15 |
25-41 HRC |
Cold-Drawn/Annealed/Aged |
130-190 |
85-120 |
30-20 |
24-35 HRC |
Hot-Finished/Aged |
140-180 |
100-135 |
30-20 |
27-37 HRC |
Cold-Rolled/Annealed |
90-105 |
40-65 |
45-25 |
85 HRB Max |
PHYSICAL PROPERTIES OF MONEL ALLOY K-500 SHEETS PLATES :
| Density : | 0.305 lbs/in³, 8.44 g/cm³ |
| Mean Coefficient of Thermal Expansion: in/in/°F (mm/m/°C): | 70- 212°F(20-100°C): 7.6 x 10-6 (13.7) |
| Modulus of Elasticity: ksi (MPa) : | 26x 10³ (179 x 10³) in Tension |
| Modulus of Elasticity: ksi (MPa) : | 26x 10³ (179 x 10³) in Tension |
Labh Steel Supplies Monel Alloy K-500 Sheets & Plates in Agartala, Agra, Agra Rampur, Ahmedabad, Aizawl, Ajmer, Aligarh, Allahabad, Alwar, Amaravati, Ambala, Ambattur, Ambernath, Amravati, Amritsar, Aurangabad, Bangalore, Bareilly, Belgaum, Bhagalpur, Bhavnagar, Bhilai, Bhiwandi, Bhopal, Bhubaneswar, Bidhannagar, Biharsharif, Bikaner, Bilaspur, Bokaro, Chandigarh, Chennai, Chittoor, Coimbatore, Cuttack, Dahod, Davanegere, Dehradun, Delhi, Dhanbad, Dharamsala, Dindigul, Diu, Durgapur, Erode, Faridabad, Fatehpur, Gandhidham, Gandhinagar, Ghaziabad, Greater Hyderabad, Greater Mumbai, Greater Warangal, Gurgaon, Guwahati, Gwalior, Haldia, Howrah, Hubballi-Dharwad, Hyderabad, Imphal, Indore, Jabalpur, Jaipur, Jalandhar, Jammu, Jamnagar, Jamshedpur, Jhansi, Jodhpur, Junagadh, Kakinada, Kalyan-Dombivali, Kanpur, Karnal, Kavaratti, Kochi, Kohima, Kolhapur, Kolkata, Kota, Lucknow, Ludhiana, Madurai, Mehsana, Mangalore, Mangaluru, Mira-Bhayandar, Moradabad, Morbi, Mumbai, Muzaffarpur, Mysore, Nagpur, Namchi, Nasik, Navi Mumbai, NDMC, Nellore, New Delhi, New Town Kolkata, Noida, Oulgaret, Pali, Panaji, Panipat, Panvel, Pasighat, Patiala, Patna, Pimpri-Chinchwad, Port Blair, Puducherry, Pune, Raipur, Rajkot, Ranchi, Raurkela, Industrial Township, Rourkela, Sagar, Salem, Satna, Secunderabad, Shaharanpur, Shillong, Siliguri, Silvassa, Solapur, Srinagar, Surat, Thane, Thanjavur, Thiruvananthapuram, Thoothukudi, Thrissur, Tiruchirapalli, Tirunelveli, Tirupur, Tumkur, Udaipur, Ujjain, Ulhasnagar, Vadodara, Vapi, Varanasi, Vasai-Virar, Vellore, Vishakhapatnam.
Labh Steel exports Monel Alloy K-500 Sheets & Plates to Countries like India, United States, United Arab Emirates, Canada, Pakistan, Peru, Chile, Spain, France, United Kingdom, Indonesia, Israel, Iran, Kuwait, Mexico, Malaysia, Nigeria, Serbia, Singapore, Taiwan, Chile, Venezuela, Ecuador, Saudi Arabia, Netherlands, Brazil, Colombia, Ghana, Iran, Denmark, Poland, Australia, Afghanistan, Bahrain, Costa Rica, Egypt, Iraq, Jordan, South Korea, Kazakhstan, Sri Lanka, Lithuania, Norway, Oman, Philippines, Poland, Qatar, Russia, Vietnam, South Africa, Nigeria, Mexico, Turkey, Hungary, Algeria, Angola, Argentina, Austria, Azerbaijan, Bangladesh, Belarus, Belgium, Bhutan, Bolivia, Bulgaria, Croatia, Czech Republic, Estonia, Finland, Greece, Italy, Japan, Libya, Romania, Thailand, Trinidad & Tobago,Tunisia, Ukraine, Yemen, Hong Kong, Gabon, China, Portugal, Switzerland, New Zealand, Sweden, Slovakia, Kenya, Lebanon, Morocco, Mongolia.
For further enquiries related to MONEL ALLOY K-500 SHEETS PLATES kindly get back to us on :- labhsteel@yahoo.co.in or contact us on +91 9869609924
