Labh Steel we are Supplier and Exporter of Stainless Steel 309 Sheets & Plates In India, Mumbai. we produce our materials using high quality raw materials for high resistance of our product. we also provide various grades ASTM A240 / ASME SA240. we also take on clients requests as per their specifications.
309 Stainless Steel is an austenitic chromium-nickel stainless steels that give incredible corrosion resistance and warmth resistance in addition to great quality at room and raised temperatures.
Designed as per national and international standards, these Stainless Steel 309 Sheets Plates are extremely long-lasting and are provided to our customers in different sizes and shapes at resonable rates.
SPECIFICATIONS OF STAINLESS STEEL 309 SHEETS & PLATES :
| Standard : | ASTM A240 / ASME SA240 |
| Range : | 0.3mm to 150mm |
| Hardness : | Hardness: Soft, Hard, Half Hard, Spring Hard, etc. |
| Finish : | Hot rolled plates (HR), Cold rolled sheets (CR), 2B, 2D, 2BB, BA, NO8, SATIN (MET with Plastic coated). |
| Form: | Coils, Foils, Rolls, Plain Sheet, Shim Sheets, Perforated Sheets, Chequered Plates, Strips, Flats, Blank (Circle), Ring (Flange) etc. |
| Other services : | Heat treatment, Annealing, Pickling, Polish, Electroplating, Anodizing, Rolling, Cutting, Forging, etc. | Width : | 1000mm / 1219mm /1250mm / 1500mm / 2000mm |
| Length : | 2000 mm / 2440 mm / 2500 mm / 3000 mm / 6000 mm. |
| Thickness of Sheets (Cold Rolled) : | Ranging from 0.3 mm to 6 mm |
| Thickness of Sheets / Plates (Hot Rolled) : | Ranging from 3.0 mm to 20 mm |
| Applications : |
|
GRADE SPECIFICATIONS OF STAINLESS STEEL 309 SHEETS & PLATES :
| Stainless Steel | Tradename | UNS no. | Werkstoff No. |
| 309 | 309 Stainless | S30909 | 2.4660 |
CHEMICAL COMPOSITION OF STAINLESS STEEL 309 SHEETS & PLATES :
| Grade | C | Si | Cr | Mo | P | Mn | S | Ni | N | |
|---|---|---|---|---|---|---|---|---|---|---|
| 309 | min. | - | - | - | - | - | - | - | - | - |
| max. | 0.08 | 1.00 | 22.00 | 0.75 | 0.045 | 2.0 | 0.030 | 12.00 | - | |
MECHANICAL PROPERTIES OF STAINLESS STEEL 309 SHEETS & PLATES :
| Grade | Yield Strength 0.2% Offset |
Ultimate Tensile Strength |
Elongation in 2 in. |
Hardness | ||
| psi (min.) | (MPa) | psi (min.) | (MPa) | % (min.) | (max.) | |
| 309 | 45,000 | 310 | 85,000 | 586 | 50 | 202 (HBN) |
PHYSICAL PROPERTIES OF STAINLESS STEEL 309 SHEETS & PLATES :
| Grade | Density lbm/in3 |
Thermal Conductivity (BTU/h ft. °F) |
Electrical Resistivity (in x 10-6) |
Modulus of Elasticity (psi x 106 |
Coefficient of Thermal Expansion (in/in)/ °F x 10-6 |
Specific Heat (BTU/lb/ °F) |
Melting Range (°F) |
| 309 | at 68°F: 0.285 | 9.0 at 32- 212°F | 30.7 at 68°F | 28.5 | 8.28 at 32 – 212°F | 0.1200 at 68°F to 212°F | 2500-2590 |
