Labh Steel is a supplier, stockist and exporter of Hastelloy C22 Strips, Sheets and plates which are also known as Nickel alloy C22, Alloy C22, UNS N06022 Strips, Sheets and plates. Hastelloy C22 is provided as per ASTM B 575; ASTM B 906 & ASME SB 575; ASME SB 906, ASME Code Case 2226, ASME Code Case N-621, ISO 6208, DIN 17750. Labh Steel provides all type of Hastelloy C22 sheets, plates, coils, strips and foils form. Labh Steel exports Hastelloy Alloy C22 Strips, Sheets & Plates from 0.27mm thick to 100mm thick with a width ranging from 10mm to 1250mm. Hastelloy C22 has excellent weld ability .Hastelloy C22 is a nickel-chromium-molybdenum-tungsten alloy with high heat resistance and corrosion resistance powers. Hastelloy C22 has corrosion resistance higher to other Ni-Cr-Mo alloys which includes Hastelloy C-276, C-4 and inconel 625. Hastelloy C22 finds its usage in Marine industry, Power industry, Chemical alkalis industry, Oil and gas Industry, Defence Industry, Military equipments, Heat Exchanger industry and Acid Plants.
At the point when contrasting the two compounds, there is little distinction in erosion safe execution with one special case; Alloy C22 Coils and Strips demonstrates a change over Alloy C276 Coils and Strips when utilized as a part of certain immersed wet chlorine situations. We offer these Hastelloy C22 Coils and Strips in specially crafted shapes and sizes according to the necessities given by our customers, and that too at a moderate and market driving costs.
SPECIFICATION :
| Specifications : | ASTM / ASME SB 575, ASTM / ASME SB 333 |
|---|---|
| Dimensions : | ASTM, ASME and API |
| Size : | 6 mm to 120 mm. |
| Length : | Single Random, Double Random & Cut Length |
| Schedule : | SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
Range: |
0.3mm to 150mm |
Form: |
Coils, Foils, Rolls, Plain Sheet, Shim Sheets, Perforated Sheets, Chequered Plates, Strips, Flats, Blank (Circle), Ring (Flange) etc. |
Hardness: |
Soft, Hard, Half Hard, Spring Hard, etc. |
Finish: |
Hot rolled plates (HR), Cold rolled sheets (CR), 2B, 2D, 2BB, BA, NO8, SATIN (MET with Plastic coated). |
Other services: |
Heat treatment, Annealing, Pickling, Polish, Electroplating, Anodizing, Rolling, Cutting, Forging, etc. |
GRADE SPECIFICATION :
| Hastelloy | Tradename | UNS no. | Werkstoff No. |
| C22 | Hastelloy C22 | N06022 | 2.4602 |
CHEMICAL COMPOSITION :
| Element | Min | Max |
|---|---|---|
| Molybdenum | 12.5 | 14.5 |
| Chromium | 20.0 | 22.5 |
| Iron | 2.00 | 6.00 |
| Tungsten | 2.50 | 3.50 |
| Cobalt | -- | 2.50 |
| Carbon | -- | 0.010 |
| Silicon | -- | 0.08 |
| Manganese | -- | 0.50 |
| Vanadium | -- | 0.35 |
| Phosphorus | -- | 0.025 |
| Sulfur | -- | 0.010 |
MECHANICAL PROPERTIES :
| Product Form | Tensile (ksi) | .2% Yield (ksi) | Elongation % | Hardness (HRb) |
|---|---|---|---|---|
| Plate (.25”-1.75”) | 112 | 53 | 62 | 89 |
| Sheet (.038”-.15”) | 122 | 63 | 54 | 93 |
| Bar (.50”-5.50”) | 115 | 55 | 60 | 89 |
PHYSICAL PROPERTIES :
| Density | 0.314 lb/in3 |
|---|---|
| Specific Gravity | 8.69 lb/in3 |
| Specific Heat (Btu/lb/Deg F - [32-212 Deg F] | 0.1 |
| Melting Point (Deg F) | 2550 |
| Thermal Conductivity | 70 |
| Mean Coeff Thermal Expansion | 6.9 |
| Modulus of Elasticity Tension | 29.9 |
