Hastelloy Alloy C22 Sheets & Plates

Hastelloy Alloy C22 Coils|Hastelloy Alloy C22 Flat|Hastelloy Alloy C22 Strips|Hastelloy Alloy C22 Blank|Hastelloy Alloy C22 Circle|Hastelloy Alloy C22 Ring|Hastelloy C22 N06022 Stockist|Hastelloy Alloy C22 Sheets & Plates Supplier In India.



ASTM A 575 Hastelloy Alloy C22 Sheets & Plates|ASME SB 575 Hastelloy Alloy C22 Sheets & Plates Exporter| Hastelloy Alloy C22 Sheets & Plates|Hastelloy Alloy C22 Sheets|Hastelloy Alloy C22 Plates|Hastelloy Alloy C22 Sheets & Plates Exporter In India.

Hastelloy Alloy C22 Sheets Plates Manufacturer Supplier Exporter

Labh Steel We as a exporter, stockist and supplier offer a wide range Hastelloy C22 Sheets in India and overseas. Hastelloy C22 Plates (UNS N06022) are used in Scrubbers, Heat exchangers, Reaction vessels, Evaporators and more. Welding can be done by gas tungsten-arc, gas metal-arc and shielded metal-arc processes. Our Alloy C22 Sheets can be cut using any conventional plasma arc cutting system. The best arc quality is achieved using a mixture of argon and hydrogen gases. Alloy C22 Plates exhibits superior welding conditions, providing excellent as-welded conditions for process applications in chemical-based industries such as food, beverage, personal care, and pharmaceutical. It has good connecting strength and is equally long lasting. With respect to international standard quality, also offers the same in customized sizes to our clients..

Our offered Alloy C22 Sheets and Plates (WNR 2.4602) is being created and planned in agreement by method for the worldwide nature of norms at our base office for to achieve the most elevated sizes of value. We further ensure that our offered Hastelloy C22 Sheets and Plates (UNS N06022) experiences different level of value testing and in addition it is given to our client as per their requirements.

SPECIFICATION :

Standard ASTM / ASME SB 575
Grade Hastelloy C22 (UNS No. N06022) Sheets & Plates
Range : 0.3mm to 150mm
Hardness : Hardness: Soft, Hard, Half Hard, Spring Hard, etc.
Finish : Hot rolled plates (HR), Cold rolled sheets (CR), 2B, 2D, 2BB, BA, NO8, SATIN (MET with Plastic coated).
Form: Coils, Foils, Rolls, Plain Sheet, Shim Sheets, Perforated Sheets, Chequered Plates, Strips, Flats, Blank (Circle), Ring (Flange) etc.
Other services : Heat treatment, Annealing, Pickling, Polish, Electroplating, Anodizing, Rolling, Cutting, Forging, etc.
Application Acetic acid/Acetic Anhydride, cellophane manufacturing, chlorine spargers, chlorination systems, circuit board etching equipment, complex acid/chemical mixtures, fans and blowers, galvanizing line equipment, gas scrubber systems, geothermal wells, HF furnaces, incineration systems, nuclear fuel reprocessing, pesticide production, phosphoric acid applications, pickling system components, plate heat exchangers, selective leaching systems, sulfur oxide cooling towers, sulfonation systems, and tubular heat exchangers.

GRADE SPECIFICATION :

Hastelloy Tradename UNS no. Werkstoff No.
C22 Hastelloy C22 N06022 2.4602

CHEMICAL COMPOSITION :

Element Min Max
Molybdenum 12.5 14.5
Chromium 20.0 22.5
Iron 2.00 6.00
Tungsten 2.50 3.50
Cobalt -- 2.50
Carbon -- 0.010
Silicon -- 0.08
Manganese -- 0.50
Vanadium -- 0.35
Phosphorus -- 0.025
Sulfur -- 0.010

MECHANICAL PROPERTIES :

Product Form Tensile (ksi) .2% Yield (ksi) Elongation % Hardness (HRb)
Plate (.25”-1.75”) 112 53 62 89
Sheet (.038”-.15”) 122 63 54 93
Bar (.50”-5.50”) 115 55 60 89

PHYSICAL PROPERTIES :

Density 0.314 lb/in3
Specific Gravity 8.69 lb/in3
Specific Heat (Btu/lb/Deg F - [32-212 Deg F] 0.1
Melting Point (Deg F) 2550
Thermal Conductivity 70
Mean Coeff Thermal Expansion 6.9
Modulus of Elasticity Tension 29.9

Labh Steel Supplies Hastelloy Alloy C22 Sheets & Plates in Agartala, Agra, Agra Rampur, Ahmedabad, Aizawl, Ajmer, Aligarh, Allahabad, Alwar, Amaravati, Ambala, Ambattur, Ambernath, Amravati, Amritsar, Aurangabad, Bangalore, Bareilly, Belgaum, Bhagalpur, Bhavnagar, Bhilai, Bhiwandi, Bhopal, Bhubaneswar, Bidhannagar, Biharsharif, Bikaner, Bilaspur, Bokaro, Chandigarh, Chennai, Chittoor, Coimbatore, Cuttack, Dahod, Davanegere, Dehradun, Delhi, Dhanbad, Dharamsala, Dindigul, Diu, Durgapur, Erode, Faridabad, Fatehpur, Gandhidham, Gandhinagar, Ghaziabad, Greater Hyderabad, Greater Mumbai, Greater Warangal, Gurgaon, Guwahati, Gwalior, Haldia, Howrah, Hubballi-Dharwad, Hyderabad, Imphal, Indore, Jabalpur, Jaipur, Jalandhar, Jammu, Jamnagar, Jamshedpur, Jhansi, Jodhpur, Junagadh, Kakinada, Kalyan-Dombivali, Kanpur, Karnal, Kavaratti, Kochi, Kohima, Kolhapur, Kolkata, Kota, Lucknow, Ludhiana, Madurai, Mehsana, Mangalore, Mangaluru, Mira-Bhayandar, Moradabad, Morbi, Mumbai, Muzaffarpur, Mysore, Nagpur, Namchi, Nasik, Navi Mumbai, NDMC, Nellore, New Delhi, New Town Kolkata, Noida, Oulgaret, Pali, Panaji, Panipat, Panvel, Pasighat, Patiala, Patna, Pimpri-Chinchwad, Port Blair, Puducherry, Pune, Raipur, Rajkot, Ranchi, Raurkela, Industrial Township, Rourkela, Sagar, Salem, Satna, Secunderabad, Shaharanpur, Shillong, Siliguri, Silvassa, Solapur, Srinagar, Surat, Thane, Thanjavur, Thiruvananthapuram, Thoothukudi, Thrissur, Tiruchirapalli, Tirunelveli, Tirupur, Tumkur, Udaipur, Ujjain, Ulhasnagar, Vadodara, Vapi, Varanasi, Vasai-Virar, Vellore, Vishakhapatnam.


Labh Steel exports Hastelloy Alloy C22 Sheets & Plates to Countries like India, United States, United Arab Emirates, Canada, Pakistan, Peru, Chile, Spain, France, United Kingdom, Indonesia, Israel, Iran, Kuwait, Mexico, Malaysia, Nigeria, Serbia, Singapore, Taiwan, Chile, Venezuela, Ecuador, Saudi Arabia, Netherlands, Brazil, Colombia, Ghana, Iran, Denmark, Poland, Australia, Afghanistan, Bahrain, Costa Rica, Egypt, Iraq, Jordan, South Korea, Kazakhstan, Sri Lanka, Lithuania, Norway, Oman, Philippines, Poland, Qatar, Russia, Vietnam, South Africa, Nigeria, Mexico, Turkey, Hungary, Algeria, Angola, Argentina, Austria, Azerbaijan, Bangladesh, Belarus, Belgium, Bhutan, Bolivia, Bulgaria, Croatia, Czech Republic, Estonia, Finland, Greece, Italy, Japan, Libya, Romania, Thailand, Trinidad & Tobago,Tunisia, Ukraine, Yemen, Hong Kong, Gabon, China, Portugal, Switzerland, New Zealand, Sweden, Slovakia, Kenya, Lebanon, Morocco, Mongolia.
