Hastelloy Alloy C276 Forged Fittings

Hastelloy C276 2.4819|Hastelloy Alloy C276 Socket Weld Forged Fittings|Hastelloy Alloy C276 SCREWED NPT Forged Fittings|Hastelloy Alloy C276 BSP Forged Fittings| Hastelloy Alloy C276 Threaded Forged Fittings|Hastelloy Alloy C276 Forged Fittings Supplier In India.



Hastelloy Alloy C276 Forged Fittings|Hastelloy Alloy C276 Forged Fittings Manufacturer In India|ANSI B16.11 Hastelloy Alloy C276 Forged Fittings, ASME B16.11 Hastelloy Alloy C276 Forged Fittings|Hastelloy C276 N10276 Exporter.

Hastelloy Alloy C276 Forged Fittings Manufacturer Supplier Exporter

Labh Steel is considered one of the advantaged manufacturers, trader, exporters and supplier of Hastelloy C276 Forged Fittings.We are a well known manufacturer of Hastelloy Forged Fittings fabricated in various grades of steel and its alloys. These are manufactured using innovative technology, top class raw material and efficient machines. These products come in different specifications and are available at industry leading prices.

We offer the same in various sorts, for example, Hastelloy C276 Forged Socket Weld Elbow, Hastelloy C276 Forged Threaded Tee, Hastelloy C276 Forged Socket Weld Cross, Hastelloy C276 Forged Threaded Couplings, etc. Our offered Alloy C276 Forged Fittings (WNR 2.4819) is being created and composed in understanding by method for the worldwide nature of norms at our framework office for to accomplish the most noteworthy sizes of value.

SPECIFICATION :

Standards ANSI/ASME B16.11 & BS3799, etc.
Specifications ASTM B564 / ASME SB564
Size 1/8” to 4”
Class 2000LBS, 3000LBS, 6000LBS, 9000LBS, etc.
Type Socket Weld (S/W) & SCREWED (SCRD) – NPT, BSP, BSPT, Threaded Fittings

GRADE SPECIFICATION :

Hastelloy Tradename UNS no. Werkstoff No.
C276 Hastelloy C276 N10276 2.4819

CHEMICAL COMPOSITION :

Element Min Max
Molybdenum 15.0 17.0
Chromium 14.5 16.5
Iron 4.0 7.0
Tungsten 3.0 4.5
Cobalt -- 2.50
Manganese -- 2.5
Carbon -- 1.0
Vanadium -- .01
Phosphorus -- 35 max
Sulfur -- .04 max
Silicon -- .03 max
Sulfur -- .08 max

MECHANICAL PROPERTIES :

Product Form Tensile (ksi) .2% Yield (ksi) Elongation %
Bar 110.0 52.6 62
Plate 107.4 50.3 67
Sheet 115.5 54.6 60
Tube & Pipe 105.4 45.4 70

PHYSICAL PROPERTIES :

Physical Property Temp., °F British Units Temp., °C Metric Units
Density 72 0.321 lb/in.3 22 8.89 g/cm.3
Melting Range 2415-2500 1323-1371
Electrical Resistivity 75 51 microhm-in. 24 1.30 microhm-m
Mean Coefficient of
Thermal Expansion
75-200 6.2 microinches/in.-°F 24-93 11.2 x 10-6 m/m•K
75-400 6.7 microinches/in.-°F 24-204 12.0 x 10-6 m/m•K
75-600 7.1 microinches/in.-°F 24-316 12.8 x 10-6 m/m•K
75-800 7.3 microinches/in.-°F 24-427 13.2 x 10-6 m/m•K
75-1000 7.4 microinches/in.-°F 24-538 13.4 x 10-6 m/m•K
Thermal Conductivity -270 50 Btu-in./ft.2 hr.-°F -168 7.2 W/m•K
-100 60 Btu-in./ft.2 hr.-°F -73 8.6 W/m•K
0 65 Btu-in./ft.2 hr.-°F -18 9.4 W/m•K
100 71 Btu-in./ft.2 hr.-°F 38 10.2 W/m•K
200 77 Btu-in./ft.2 hr.-°F 93 11.1 W/m•K
400 90 Btu-in./ft.2 hr.-°F 204 13.0 W/m•K
600 104 Btu-in./ft.2 hr.-°F 316 15.0 W/m•K
800 117 Btu-in./ft.2 hr.-°F 427 16.9 W/m•K
1000 132 Btu-in./ft.2 hr.-°F 538 19.0 W/m•K
Specific Heat
(Calculated)
Room 0.102 Btu/lb.-°F Room 427 J/kg•K

Labh Steel Supplies Hastelloy Alloy C276 Forged Fittings in Agartala, Agra, Agra Rampur, Ahmedabad, Aizawl, Ajmer, Aligarh, Allahabad, Alwar, Amaravati, Ambala, Ambattur, Ambernath, Amravati, Amritsar, Aurangabad, Bangalore, Bareilly, Belgaum, Bhagalpur, Bhavnagar, Bhilai, Bhiwandi, Bhopal, Bhubaneswar, Bidhannagar, Biharsharif, Bikaner, Bilaspur, Bokaro, Chandigarh, Chennai, Chittoor, Coimbatore, Cuttack, Dahod, Davanegere, Dehradun, Delhi, Dhanbad, Dharamsala, Dindigul, Diu, Durgapur, Erode, Faridabad, Fatehpur, Gandhidham, Gandhinagar, Ghaziabad, Greater Hyderabad, Greater Mumbai, Greater Warangal, Gurgaon, Guwahati, Gwalior, Haldia, Howrah, Hubballi-Dharwad, Hyderabad, Imphal, Indore, Jabalpur, Jaipur, Jalandhar, Jammu, Jamnagar, Jamshedpur, Jhansi, Jodhpur, Junagadh, Kakinada, Kalyan-Dombivali, Kanpur, Karnal, Kavaratti, Kochi, Kohima, Kolhapur, Kolkata, Kota, Lucknow, Ludhiana, Madurai, Mehsana, Mangalore, Mangaluru, Mira-Bhayandar, Moradabad, Morbi, Mumbai, Muzaffarpur, Mysore, Nagpur, Namchi, Nasik, Navi Mumbai, NDMC, Nellore, New Delhi, New Town Kolkata, Noida, Oulgaret, Pali, Panaji, Panipat, Panvel, Pasighat, Patiala, Patna, Pimpri-Chinchwad, Port Blair, Puducherry, Pune, Raipur, Rajkot, Ranchi, Raurkela, Industrial Township, Rourkela, Sagar, Salem, Satna, Secunderabad, Shaharanpur, Shillong, Siliguri, Silvassa, Solapur, Srinagar, Surat, Thane, Thanjavur, Thiruvananthapuram, Thoothukudi, Thrissur, Tiruchirapalli, Tirunelveli, Tirupur, Tumkur, Udaipur, Ujjain, Ulhasnagar, Vadodara, Vapi, Varanasi, Vasai-Virar, Vellore, Vishakhapatnam.


Labh Steel exports Hastelloy Alloy C276 Forged Fittings to Countries like India, United States, United Arab Emirates, Canada, Pakistan, Peru, Chile, Spain, France, United Kingdom, Indonesia, Israel, Iran, Kuwait, Mexico, Malaysia, Nigeria, Serbia, Singapore, Taiwan, Chile, Venezuela, Ecuador, Saudi Arabia, Netherlands, Brazil, Colombia, Ghana, Iran, Denmark, Poland, Australia, Afghanistan, Bahrain, Costa Rica, Egypt, Iraq, Jordan, South Korea, Kazakhstan, Sri Lanka, Lithuania, Norway, Oman, Philippines, Poland, Qatar, Russia, Vietnam, South Africa, Nigeria, Mexico, Turkey, Hungary, Algeria, Angola, Argentina, Austria, Azerbaijan, Bangladesh, Belarus, Belgium, Bhutan, Bolivia, Bulgaria, Croatia, Czech Republic, Estonia, Finland, Greece, Italy, Japan, Libya, Romania, Thailand, Trinidad & Tobago,Tunisia, Ukraine, Yemen, Hong Kong, Gabon, China, Portugal, Switzerland, New Zealand, Sweden, Slovakia, Kenya, Lebanon, Morocco, Mongolia.
